洛杉磯機房位于洛杉磯市中心的One Wilshire大樓,One Wilshire大廈樓高30層,面積有656000平方英尺的,位于洛杉磯市區S.Grand Avenue和Wilshire Boulevard的交叉口,是北美網絡數據交換集中地,為電信公司提供無與倫比的網絡連接,為用戶提供通達美國、歐洲、非洲、香港、臺灣、日本等地區的高品質海外電信服務, 包括:主機托管,主機租賃,國際專線,網絡外包等服務。
提供全方位的解決方案,從售前咨詢到線路申請、網絡構架到硬件采購、調試設定到品質保障,均由專業CCIE工程師提供一系列周全的保障。
One Wilshire大廈為太平洋沿岸地區首屈一指的通訊樞紐,是電信行業內的國際品牌以及美國西部唯一的最重要網絡連接點。
One Wilshire是美國及全球電信行業里幾乎所有市場領導者的歸屬地。目前已經覆蓋了超過240家電信服務提供商,其中包括:AT&T, Broadwing, Cable & Wireless, Global Crossing, Level 3 Communications, Worldcom, PacBell, Qwest Communications, Sprint, Time Warner, Verizon and XO Communications等。
One Wilshire大廈具有完善的IDC基礎設施,適應電信客戶群的具體需要,具有多路供電,備用發電,防火設施,高效空調等先進設施,機房服務器均為DELL及SuperMiscro品牌服務器,也確保快速、穩定的滿足用戶的服務器擴容需求。并提供MicroSoft SPLA認證,所有軟件均為MicroSoftsh授權。
機房網絡設備均采用思科設備,目前具有千兆交換機,千兆防火墻,千兆路由器,入侵檢測系統,流量監控設備等網絡核心設備,及7×24小時的思科認證工程師隊伍。
機房互聯網帶寬由多家美國主流電信運營商的線路構成,提供合計5G的互聯網帶寬,直連美國骨干網絡,并與中國電信的中國出口直接接駁,所以機房從中國及全球都有快速和穩定的訪問速度。
| Facility | One Wilshire Campus | One Wilshire Building |
|---|---|---|
| Description | Located in the what was previously the United States Postal Service Terminal Annex building in Downtown Los Angeles, this premium Tier 4 datacenter features all the amenities associated with the highest-end data centers. The building is neighboring Union Station, so public transportation is readily available. The Original Philippe’s—a casual eatery that's home to a world famous French Dip sandwich—is also right across the street. | Located in Downtown Los Angeles this premium Tier 4 datacenter is the preeminent telecommunications hub on the west coast and features all the amenities associated with the highest end datacenters. Home to the Meet Me Room One Wilshire has tens of thousands of cross-connections making it perhaps the most interconnected space in the entire world. |
| Year Built | Originally built in 1940, the building has been renovated to accommodate the needs of telecommunications companies. | Originally constructed in 1966, the building has undergone extensive renovations for the precise needs of telecommunication companies./td> |
| TIA Tier | IV | IV |
| Independent Auditors | SSAE 16 Type 2 Compliance | SSAE 16 Type 2 Compliance |
| Power | One Wilshire Campus currently has four (4) 34,500 Volt switch vaults. Each 34,500 Volt switch vault feeds two (2) transformers for a total of eight (8) 3750kVA transformers (24 Gross MW) with an additional 10 MW pending construction. The Campus maintains seven (7) 2,000 kW generators and onsite fuel storage to run generators for up to 48 hours. | One Wilshire Building is equipped with four (4), 3750 KVA, 480 volt transformers and one (1), 5,000 KVA, 4160 transformer all fed by the Department of Water and Power. The Building maintains five (5) 2,000 kW generators and onsite fuel storage to run generators for up to 48 hours. |
| UPS System | 2N and N+1 AC and 2N DC UPS systems | N+1 AC UPS |
| Power Density | Up to 25 kW per cabinet | Up to 6.25 kW per cabinet |
| Dual-interlock, dry-pipe pre-action fire suppression system with VESDA | Dual-interlock, dry-pipe pre-action fire suppression system with VESDA | |
| HVAC Chiller Plants | N+1 cooling system configuration | N+1 cooling system configuration |
| Security | 24x7 Staffing and site access, Mantraps, Biometric access control, CCTV surveillance | 24x7 Staffing and site access, Mantraps, Biometric access control, CCTV surveillance |
| Shipping/Receiving | Facility is equipped with a security controlled loading dock, and freight elevators | The facility features a security controlled loading dock for shipping and receiving, as well as a freight elevator for larger equipment. |
| Datacenter Floor Construction | 18" Raised Floor | Concrete Slab |
